Atlas Komfort

Onto a completed drywall or masonry partition, it can safely support a kitchen unit or other furniture, depending on where in the living space the pocket door frame is located. The Atlas Komfort pocket door frame is intended for wooden or all-glass doors from any door producer. Our own MASTER DOOR and IDEA DOOR are also suitable. For standard passage heights of 1,970 mm and 2,100 mm, we produce casings by a unique wedging method, and for custom passage heights we deliver a welded pocket door frame. For a masonry partition, it is necessary to equip the construction opening with a lintel — the pocket door frame cannot bear a load. The whole frame is made of high-quality galvanized sheet metal.

• intended for a minimum finished partition thickness of 150 mm
• use for drywall and masonry partitions
• optional custom dimensions to passage height of 2,400 mm
• maximum weight of each door leaf 120 kg
• high-quality, very quiet sliding mechanism in a special aluminium rail
• removable upper rails
• adjustable front stop (rear stop is installed during production)
• a synchronizing mechanism is included
• guide pin with precise delimitation to the centre of the casing
• a switch can be placed on the casing pocket
• sliding mechanisms and fixtures for wooden doors are part of the casing
• lifetime warranty

At extra charge:

• damping stop available at additional charge. To damp both sides, two single-sided door stops must be used

Installation of the Vetro 22 fixture

• galvanized sheet metal
• aluminium profiles
• aluminium rail

• not painted
