Single-leaf
Pure Standard
Atypical PURE pocket door frame with lifetime warranty for single-leaf doors. It differs from other models mainly by its size. The width of the opening is up to 2,000 mm and the height is kept at a respectable 2,700 mm
About the product
It is a non-standard pocket door frame for large passages, designed for single-leaf sliding doors.
- Intended for a minimum finished partition thickness of 150 mm,
- use for drywall and masonry partitions,
- net passage after fitting of lining 2,000 x 2,700 mm
- optional custom dimensions to passage height of 2,700 mm,
- maximum weight of each door leaf 120 kg,
- high-quality, very quiet sliding mechanism in a special aluminium rail,
- compatible with all makes of door,
- adjustable front stop,
- a switch can be placed on the casing pocket,
- sliding mechanisms and fixtures for wooden doors are part of the casing,
- lifetime warranty.
At extra charge:
- to mount an all-glass door leaf, a Vetro 22 fixture must be ordered
Gallery / inspiration
Technical information
| Standard width of passage | 1,200 - 2,450 mm |
| Standard height of passage | 1,970 - 2,700 mm |
| Minimal thickness of finished crossbar | 150 mm |
| Maximum weight of each door leaf | 120 kg |
Manuals, certificates
Video installation manual
Painting
- not painted
Materials
- galvanized sheet metal
- aluminium rail
